Forensic Tools for in-depth Performance Investigations

nic jansma | SOASTA | nicj.net | @nicj

philip tellis | SOASTA | bluesmoon.info | @bluesmoon

Who Are We?

Nic Jansma

SOASTA

Philip Tellis

SOASTA

What We Do

SOASTA mPulse is a Real User Monitoring (RUM) tool for measuring page load performance

What We Do

We have a JavaScript library (Boomerang) that captures performance metrics, page load characteristics, XHRs, SPA navigations, and more
We are a third-party script provider
We serve boomerang.js from a CDN to our customers using a script loader snippet they include in their HTML
We can update our customer's boomerang.js version (if they ask)
Our script runs in their page so we have to be super-duper careful

Boomerang

Created by Philip Tellis @ Yahoo
Gathers performance metrics and characteristics of the page load and beacons that data to your server (aka RUM)
Open-source project (with contributions from SOASTA)
https://github.com/lognormal/boomerang/

Non-Blocking Script Loader Pattern

lognormal.com/blog/2012/12/12/the-script-loader-pattern
Better than <script> nodes or async
Uses an anonymous IFRAME


(function(url){
  // Section 1
  var dom,doc,where,iframe = document.createElement('iframe');
  iframe.src = "javascript:void(0)";
  iframe.title = ""; iframe.role="presentation";  // a11y
  (iframe.frameElement || iframe).style.cssText = "width: 0; height: 0; border: 0";
  where = document.getElementsByTagName('script');
  where = where[where.length - 1];
  where.parentNode.insertBefore(iframe, where);

  // Section 2
  try {
    doc = iframe.contentWindow.document;
  } catch(e) {
    dom = document.domain;
    iframe.src="javascript:var d=document.open();d.domain='"+dom+"';void(0);";
    doc = iframe.contentWindow.document;
  }
  doc.open()._l = function() {
    var js = this.createElement("script");
    if(dom) this.domain = dom;
    js.id = "js-iframe-async";
    js.src = url;
    this.body.appendChild(js);
  };
  doc.write('<body onload="document._l();">');
  doc.close();
})('http://some.site.com/script.js');

Customer Concerns

What happens when our customers think our third-party script is causing an issue on their site?

We bust out our favorite tools!

Scenario #1

Aren't you supposed to be non-blocking?

Customer:

"Hi guys, So, I was running some WPT tests today and saw this… I thought that this was supposed to be non-blocking. If anyone sees this, they'll hang me up by my heels."

Screenshot #2 from our customer:

Step #1

Reproduce the Issue

Tool #1

WebPageTest

For reproducing real-world page load scenarios
For testing Single Points of Failure (SPOF)
Can give you: waterfalls, TCP dumps, network and processing breakdowns, traces, net logs, screenshots, videos, Page Speed score, comparisons and more

Step #1

Reproduce the Issue

The customer shared their WebPageTest results URL, and we looked closer at the test pass

Out of the 9 runs, 2 showed what appeared to be boomerang.js blocking other downloads

Repro #1:

Repro #1 Larger view

Repro #2:

Step #2

Dive Deeper

We looked at the 9 test runs, and found 3 more that had some sort of period where nothing happens

The tests show periods of time where the CPU is 100%, and bandwidth (bytes transferred) drops to 0 for 1-4 seconds.

Repro #1 and #2 show 100% CPU and no bandwidth for over a second:

Non-repros: boomerang.js loaded quickly, but two images appeared to "hang"

Non-repros: boomerang.js loaded much earlier, but other content appears to "hang"

Non-repros: Other content "hanging"

WebPageTest has many options for diving deeper

WebPageTest

Processing Breakdown

Gives a breakdown of main thread processing and timeline

Processing Breakdown

Tool #2

tcpdump

Packet capturing, viewing and analysis
libpcap is a portable library for capturing

tcpdump

tcpdump.org/manpages/tcpdump.1.html

tcpdump -nS

Tool #3

Wireshark

Higher-level analysis of tcpdump

Wireshark

Tool #4

CloudShark

Analyze PCAP (tcpdump) files in your browser

CloudShark

At this point, we downloaded the WebPageTest tcpdump files to dive deeper into the data

In all of the runs that showed a period of "no progress", we found zero network activity

(Repro #1)

We expect the OS network stack to continue TCP communications even if the browser was "blocked" on a script

CloudShark

(Repro #2)

Tool #5

Browser Dev Tools

Tool #5

Browser Dev Tools

The usefulness of Browser Dev Tools could be a talk on its own, but we'll give some highlights during our investigations

Tool #6

Chrome Tracing

chrome://tracing

WebPageTest provides Chrome Traces

Chrome Trace

Repro #2:

Chrome Trace

Repro #2:

Netlog

NetLog: Chrome’s network logging system

https://www.chromium.org/developers/design-documents/network-stack/netlog

Repro #2: Netlog


{"params":{"load_flags":2163712,"method":"GET","priority":"LOWEST",
    "url":"http://c.go-mpulse.net/boomerang/KQTS5-4NBTD-EYGLE-64UYR-S5892"},
    "phase":1,"source":{"id":588,"type":1},"time":"5454412310","type":91},
{"phase":1,"source":{"id":588,"type":1},"time":"5454412310","type":93},
{"phase":2,"source":{"id":588,"type":1},"time":"5454412310","type":93},
{"phase":1,"source":{"id":588,"type":1},"time":"5454412310","type":101},
{"phase":2,"source":{"id":588,"type":1},"time":"5454412310","type":101},
{"phase":1,"source":{"id":588,"type":1},"time":"5454412310","type":102},
{"params":{"byte_count":1460},"phase":0,"source":{"id":275,"type":4},
    "time":"5454412311","type":62},
{"phase":2,"source":{"id":529,"type":1},"time":"5454412311","type":143},
{"phase":1,"source":{"id":529,"type":1},"time":"5454412311","type":143},
{"params":{"byte_count":443},"phase":0,"source":{"id":275,"type":4},
    "time":"5454412313","type":62},
{"phase":2,"source":{"id":529,"type":1},"time":"5454412313","type":143},
{"phase":1,"source":{"id":529,"type":1},"time":"5454412313","type":143},
{"phase":2,"source":{"id":275,"type":4},"time":"5454412313","type":37},
{"phase":2,"source":{"id":529,"type":1},"time":"5454412313","type":143},

Step #2

Dive Deeper

It will be great to (re)prove that our script loader works even if our CDN is down, or if there are delays in the network

How can we do this? There are a couple tools that can help with Single Point of Failure (SPOF) testing

WebPageTest SPOF

blackhole.webpagetest.org drops all traffic


setDnsName c.go-mpulse.net blackhole.webpagetest.org
navigate our-customer.com

WebPageTest SPOF

No issues with blocking our CDN c.go-mpulse.net

Let's try to do SPOF on our local machine as well

Browser Dev Tools

Waterfall

Tool #7

/etc/hosts

Great for quickly redirecting traffic to your local machine
Or for sending traffic to a blackhole

On Windows: C:\windows\system32\drivers\etc\hosts

/etc/hosts

blackhole.webpagetest.org == 72.66.115.13


72.66.115.13 apis.google.com
72.66.115.13 www.google-analytics.com
72.66.115.13 c.go-mpulse.net

Tool #8

Fiddler

For monitoring all traffic from desktop or mobile devices
For injecting different content into live sites
For artifically delaying traffic

Fiddler

Fiddler SPOF

Scenario #1

Conclusion:

Able to reproduce the issue on WebPageTest that day, but not later
Saw periods of no CPU activity
Saw periods of no TCP activity
Boomerang had already reached the network interface, so something else was blocking it on the box
Customer had multiple tag managers

Scenario #1

Conclusion:

We ran SPOF checks with WebPageTest, /etc/hosts, and Fiddler
Via WPT and Fiddler SPOF, we show our script is non-blocking

Scenario #2

Pre-render shenanigans

Customer:

"I'm seeing pages that should match showing up in No Page Group again"

You can define rules in mPulse for URLs to be matched to a Page Group dimension
Customer was seeing a high number of hits to a (No Page Group) category that should have matched a URL

Page Groups

Tool #9

RUM

Real User Monitoring (RUM) tools
Real world data
Look at data in aggregate

Disclaimer

We obviously work for SOASTA, and mPulse is our RUM product

RUM

Aggregate Data

RUM lets you view your real-world customer data from an aggregate level

RUM

What are the most common causes of (No Page Group)?

iOS Mobile Safari sticks out:

RUM Waterfalls

RUM Waterfalls let you look at real-world individual page loads

Step #1

Reproduce the Issue

From RUM data, the issue was most common on the home page from iOS devices.
Time to reproduce the issue on an iPad!

Fiddler

One great use of Fiddler is to monitor external browser traffic without having Browser Dev Tools open (including mobile traffic!)

At this point, we sat with an iPad, reloading the home page hundreds of times to try to get a repro...

And tried...

... an hour later, after trying many ways of loading the home page, we finally got a hit!

The Repro

It just so happens I was typing www.customer.com in the address bar, but got a phone call, so didn't hit Go yet
Saw a beacon go through without a Page Group attached, but clearly for the customer's home page
Ran the same scenario again, same result. Repro!
Mobile Safari was pre-rendering the page I was typing into the address bar

Step #2

Dive Deeper

Now that we had a repro, we were able to narrow down the issue to a bug in Boomerang that didn't deal with pre-render state transitions properly.

The fix was pretty straightforward, but we needed to test it.

Fix Validation

Fiddler allows you to inject your own content in place other live content on any host

We injected our fixed version into the customer' site, and validated that it worked

Scenario #2

Conclusion:

We used RUM to narrow down the problem
We used RUM waterfalls to validate the problem happens in real-world data
We used tools like Fiddler help reproduce the issue
We used tools like Fiddler to help validate the fix

Scenario #3

Stop messing with my readyState

Scenario #3

We were loading www.customer.com and found that Boomerang wasn't reliably sending a Page Load beacon
Boomerang should run on window.onload and fire a beacon, but this wasn't happening

Step #1

Reproduce the Issue

After injecting a debug version of Boomerang (via Fiddler) onto the customer's site, we found some interesting logging statements
For example, document.readyState == "loading" even though window.onload had fired
window.pageshow was firing before window.onload -- window.onload should be first

Step #2

Dive Deeper

Our guess was that there was a script running on our customer's site that was messing with some of the document loading states, but had to prove it

One way is to fetch, unminify and analyze all of the site's JavaScript, but there are a couple easier ways if you want to use the Browser Dev Tools to work for you

Tool #9

TamperMonkey

"Userscript" manager for Chrome, Opera and Android
Allows you to inject your own code in other sites without a proxy

We started out with a guess that something was changing window.onload or document.readyState

Easy way to see

One way of modifying pre-existing DOM properties is via Object.defineProperty

Inject this in the page to find anyone using it:


Object.defineProperty = function(obj, prop, descriptor) {
  debugger;
};

Hit!

Chrome/IE/FF pretty-print (unminify) is the greatest thing

We also a similar change of document.readyState


Object.defineProperty(
  document,
  "readyState",
  {
    get:
      function()
      {
        return document.someOtherReadyState;
      }
  });

Scenario #3

Conclusion:

Changes to window.onload and document.readyState were intentional by another third-party script for FEO optimization
We worked with that third-party to ensure our performance instrumentation wouldn't be affected

Scenario #4

Premature optimization is the root of all good intentions

Scenario #4

Our mPulse beacons are protected against CSRF by a token and timestamp that gets sent with each beacon
The CSRF token times out after 5 minutes
A new token/timestamp is fetched from our servers every 5 minutes to ensure long-running apps can continue to send beacons

Scenario #4

We were finding that there was an increasing occurence of the timestamp being "too old" -- that the CSRF timestamp on beacons were over 5 minutes old
These beacons get dropped, but we needed to figure out why

Step #1

Reproduce the Issue

Every beacon that gets sent to mPulse is permanently persisted (stripped of PII), so we can easily go back and investigate the raw data
Every dropped beacon is logged along with why it was dropped
These dropped beacons don't hit our reporting infrastructure, but we still want to be able to look for trends among the dropped beacons

Tool #10: NodeJS

Great for writing throw-away analysis scripts
JavaScript lets you quickly iterate
Tons of NPM modules for command-line use

NodeJS

We use NodeJS for many things at SOASTA:

boomerang.js build, deployment and testing (Grunt/Jenkins)
Infrastructure tools
Raw data analysis

NodeJS

Useful NodeJS NPM modules for command-line scripts:

jetty: ANSI control sequences
fast-stats: Statistical analysis of numeric datasets
cli-table: Tables for the command-line
commander: Command-line argument parsing
line-by-line: Reads large files without buffering into memory

Step #2

Dive Deeper

We fetched gigabytes of dropped-beacon log files, and started doing some statistical analysis on the causes

Dropped-beacon Breakdown

We can break down the dropped-beacons data by dimensions to help guide us towards finding a repro:

By browser
By OS
By beacon type
By URL

Dropped-beacon Breakdown

NodeJS cli-table output. By browser:

┌──────────────────────────────┬──────────┬──────────┐
│ URL                          │ Count    │ %        │
├──────────────────────────────┼──────────┼──────────┤
│ IE/7.0                       │ 1559     │ 66.65    │
├──────────────────────────────┼──────────┼──────────┤
│ IE/9.0                       │ 293      │ 12.53    │
├──────────────────────────────┼──────────┼──────────┤
│ Safari/5.1.9                 │ 283      │ 12.10    │
├──────────────────────────────┼──────────┼──────────┤

Dropped-beacon Breakdown

NodeJS cli-table output. By beacon type:

┌──────────────────────────────┬──────────┬──────────┐
│ URL                          │ Count    │ %        │
├──────────────────────────────┼──────────┼──────────┤
│ xhr                          │ 2222     │ 95.00    │
├──────────────────────────────┼──────────┼──────────┤
│ navigation                   │ 37       │ 1.58     │
├──────────────────────────────┼──────────┼──────────┤
│ ...                          │ 7        │ 0.30     │
├──────────────────────────────┼──────────┼──────────┤
│ Total                        │ 2339     │ 100      │
└──────────────────────────────┴──────────┴──────────┘

Dropped-beacon Breakdown

NodeJS cli-table output. By URL:

┌───────────────────────────────────────┬──────────┬──────────┐
│ URL                                   │ Count    │ %        │
├───────────────────────────────────────┼──────────┼──────────┤
│ http://www.customer.com/api/foo       │ 2187     │ 93.50    │
├───────────────────────────────────────┼──────────┼──────────┤
│ http://www.customer.com/anotherurl    │ 9        │ 0.38     │
├───────────────────────────────────────┼──────────┼──────────┤

The Repro

From our raw data, the "too old" beacons were mostly caused by IE 7 and IE 9, from XHRs to the customer's /api/foo endpoint

Tool #11

Virtualization

VirtualBox, VMWare, Parallels, etc
All great ways to test older browsers
modern.ie has VMs for IE 6, 7, 8, 9, 10, 11 and Edge

The Repro

We sat our VirtualBox IE 9 browser on www.customer.com for a while, watching XHRs and beacons flow past

The Repro

Both IE 9 Developer Tools and Fiddler showed something interesting:

The Repro

IE 9 Developer Tools showing aborted requests to our injected <javascript> that updates the token and timestamp:

Scenario #4

Conclusion:

We had recently made a change in boomerang.js to quickly remove the <javascript> node that was fetching the updated CSRF token and timestamp
In some older browsers, this causes the network request to abort
We were able to validate the fix (keeping the <javascript> node around for a bit) via the same tools

Scenario #5

The many ways to send a beacon

... and the many ways to not send a beacon

Scenario #5

We send the boomerang.js beacon to mPulse via several methods:

If the payload is small, we create a hidden IMG element with a img.src containing the payload in the query string
If the payload is large (greater than 2083 bytes), we create a hidden FORM element and call form.submit() on it

Scenario #5

Windows 10 and Edge had just been released, and a customer reported that their site was hanging in Edge on some pages, and that it no longer did when boomerang.js was removed from their site

We had tested Windows 10 Techincal Preview (the previous Edge build) thoroughly, but something in the final release was causing problems

Step #1

Reproduce the Issue

Sure enough, loading customer.com would hang Edge for up to 30 seconds.

Since the browser was hung, it was hard to use the Edge debugger

Step #2

Dive Deeper

Time to dive into system-level tracing!

Tool #12

Event Tracing for Windows

Event Tracing for Windows (ETW) is built into all versions of Windows from XP onward
Enables the OS and applications to efficiently generate runtime tracing events
xperf and the newer Windows Performance Analyzer (WPA) are tools used to generate ETW traces and then analyze them

ETW

Available tracing:

CPU usage
Disk usage
Hard faults
DPCs/ISRs
TCP
Sampled Profiling
Custom app events (IE7+, Chrome)
With stacks!

ETW - Downloading

Part of the Windows Performance Toolkit
Included in the Windows Assessment and Deployment Kit
Friendly interface via UIforETW: github.com/google/UIforETW

ETW - Usage

Simple trace of system evenst:


xperf.exe -on latency -stackwalk profile
// [run scenario]
xperf.exe -stop -d myscenario.etl

ETW - xperfview

Timeline of events
Filter processes
Graph selection

xperf - Summary Tables

All of the graphs can be interacted with - zoom, popups, right-clicks
Summary Tables show data in tabular form

ETW - Browser Events

Internet Explorer and Chrome both fire ETW events that you can overlay in the charts and see in the tables

ETW - IE Events

Microsoft-IE events:

CMarkup_OnLoadStatusDone: Page load is complete
CDoc_OnPaint: Paints
CDwnBindData_Bind: Downloads
+ 100s more

Microsoft-IEFRAME:

Frame events for tabs, navigations, history, extensions

UserTiming in ETW


performance.mark("startTime1");
performance.mark("endTime1");
performance.mark("startTime2");
performance.mark("endTime2");
performance.measure("durationTime1", "startTime1", "endTime1");
performance.measure("durationTime2", "startTime2", "endTime2");

ETW - Stacks

By using -stackwalk on the command line, you can enable stacks on many events

Public symbol servers:

https://msdl.microsoft.com/download/symbols

http://symbols.mozilla.org/firefox

https://chromium-browser-symsrv.commondatastorage.googleapis.com/

ETW - More Help

More great tutorials on ETW, UIForETW, and xperf are available at: randomascii.wordpress.com

via Bruce Dawson @BruceDawson0xB

ETW - Uses

Slow page load performance? Take a trace!
See page load from a system-wide perspective
Isolate page load from interference due to other CPU/disk/network activity
Compare browser page load times and resource usage
Examine browser CPU usage hot-spots from sampled profile stacks
Automated page load regression testing of browsers via command-line tools
Integrate page load time / cpu usage metrics into your build system

The Repro

Using Windows 10 (in a VirtualBox VM?)
Open Edge
xperf -on latency -stackwalk profile
Head to www.customer.com
We immediately see the browser go to (Not Responding)
xperf -d repro.etl

WPA - CPU sampling

The trace shows Edge spending nearly 100% CPU for over 70 seconds:

CPU sampling stacks

Dive Depeer

With the repro, after a lot of digging around, we found that the way we were sending large beacons, via a hidden FORM submission, was triggering this Edge hang
But only if our server was returning either a:
- 200 OK response, or
- 204 No Content response that was missing a Content-Length: 0 header.

Validation

We were able to test different fixes across our test matrix (IE 6 - Edge, Chrome, Firefox, Safari, Mobile Safari, Android, Lynx, etc) using Fiddler

Conclusion

When you really need to look at a problem wholistically, system-level tracing is the only way to go
ETW (or things like DTrace on Mac/Linux) can give you a different perspective, and show you CPU, disk, network, and other system activity occuring during your scenario
